Rivet Storage Shelving, with 5 to 8 Shelves (3' 0"W x 2' 6"D x 7' 0"H), #SMS-39-SRS363084
steel shelving similar to Rivetwell Penco WPSS Rivetier Western Pacific Edsal Tennesco boltless
Decking not included (see optional decking). All units are priced with 5 shelves, but you can select units with 6, 7, or 8 shelves.
Alternative Views:

Free Dock to Dock Shipping

Rivet Storage Shelving

Rivet storage shelving is engineered to be assembled without the use of fasteners. All units are priced with 5 shelves, but you can select 6, 7, or 8 shelf units. Decking not included. Click here for optional wood or wire decking. Posts and beams are made of steel. Assembles with a rubber mallet.

See more Boltless Shelving Units
List Price: $200.53
Our Price: $145.69 (Free Dock to Dock Shipping)*
You save $54.84!

Price with Selected Options: $145.69
Dimensions: 3' 0"W x 2' 6"D x 7' 0"H
Opening: Choose from 5 to 8 shelves
Type: Boltless Steel Shelving
Other: Decking not included (see optional decking)
Weight: 54 Lbs.

Availability: Ships in 4-5 Business Days
Product Code: SMS-39-SRS363084

Click thumbnail to view choice

Number of Shelves:
5 Shelves
6 Shelves [Add $14.37]
7 Shelves [Add $28.71]
8 Shelves [Add $43.07]
Shipping Instructions

I agree with shipping instructions*:
I understand the shipping informationyoutube red icon

I agree to the shipping terms covering "free shipping" and "inspecting your freight" for damage listed in the Shipping Document. If "Inside Delivery" or other freight services are needed, call 1-855-786-7667 for a quote.



Rivet Storage Shelving

3' 0"W x 2' 6"D x 7' 0"H, SMS-39-SRS363084

Boltless rivet type shelving components are engineered to attach snugly together without the use of fasteners. This unique boltless design uses rivet tabs which are factory attached to all beams. The beam's rivet tabs hook into keyhole slots in the vertical posts. Components are tapped into place using a rubber mallet. Optional particleboard decking can be purchased for the units or you can supply your own decking materials.

Boltless Shelving Construction & Features

  • Uprights: Each unit includes four 1-1/2" x 1-1/2" angle upright posts 84" high made from 14-gauge cold rolled steel. Posts can be cut down ordered shorter or cut down with a metal saw if desired.
  • Top & Bottom Shelves/Beams: Top and bottom shelves use double rivet left-to-right and front-to-back beams for full perimeter support and stability.
  • Intermediate Shelves/Beams: One of the intermediate shelves includes two front-to-back side shelf supports. All other shelves include left-to-right beams only. 30" and 36" deep shelving units include front-to-back side shelf supports on all levels.
  • Load Capacity: Load capacity for 36" wide shelves is 350 lbs. per shelf level. Load capacity for 48" wide shelves is 250 lbs. per shelf level. Load capacity is based on non-impact evenly distributed weight loads.
  • Decking: Shelf units come standard without decking. Optional particleboard or wire decking can be added. Wire decking is available on indicated models only.
  • Shelving units available with 5, 6, 7, and 8 shelves
  • Dimensions: For actual unit dimensions, add 1/2" to the width and depth of all units (example 36" wide unit actual measurement is 36 1/2" 24" deep unit actual measurement is 24-1/2")
  • Ships unassembled. Assembles using a rubber mallet.
  • Tan Color
  • One Year Manufacturer's Warranty
  • Made in the U.S.A.

decking options
size (width x depth) wood wire
3' x 1' (36" x 12") SMS-39-HPB3612 N/A
3' x 1' 6" (36" x 18") SMS-39-HPB3618 SMS-39-HWD3618
3' x 2' (36" x 24") SMS-39-HPB3624 SMS-39-HWD3624
3' x 2' 6" (36" x 30") SMS-39-HPB3630 SMS-39-HWD3630
3' x 3' (36" x 36") SMS-39-HPB3636 SMS-39-HWD3636
4' x 1' (48" x 12") SMS-39-HPB4812 N/A
4' x 1' 6" (48" x 18") SMS-39-HPB4818 SMS-39-HWD4818
4' x 2' (48" x 24") SMS-39-HPB4824 SMS-39-HWD4824
4' x 2' 6" (48" x 30") SMS-39-HPB4830 SMS-39-HWD4830
4' x 3' (48" x 36") SMS-39-HPB4836 SMS-39-HWD4836
